ware_ops_algos¶

ware_ops_algos is a library that aims to provide standardized implementations of algorithms for warehouse operations such as order batching, picker routing, item assignment, and picker scheduling.

Key Features¶

🏗️ Extensible Domain Model: Structured domain models for layouts, orders, storage, and resources
🔧 Algorithm Repository: Ready-to-use implementations for batching, routing, assignment, and sequencing
🎯 Algorithm Cards: Annotation of algorithm properties and requirements in the form of algorithm cards

Domain Model¶

The library uses a flexible domain model to represent warehouse systems. Instead of enforcing a rigid data structure, domain objects capture varying contextual information organized by distinct aspects of the warehouse system.

Domain Objects¶
Domain	Description	Key Attributes
Layout	Spatial structure of the warehouse	Type (conventional/unconventional), parametric form or explicit graph
Articles	Master data of warehouse items	Weight, volume, handling classes
Orders	Customer orders to be fulfilled	Order lines, arrival time, due date
Resources	Picking agents (human or robotic)	Travel speed, handling time, pick cart configuration
Storage	Warehousing configuration	Storage policy, inventory levels, location coordinates

Algorithm Repository¶

All algorithms inherit from an abstract Algorithm base class providing a unified interface through solve(), which handles timing and error management.

Algorithm (abstract)
├── ItemAssignment      # Resolve order lines to storage locations
├── Batching            # Group orders into picker tours
├── Routing             # Determine paths through the warehouse
└── Scheduling          # Sequence and assign tours to pickers

Item Assignment — For scattered storage where articles may be stored at multiple locations. Approaches include greedy allocation and nearest-neighbor selection.

Batching — Groups orders into batches subject to capacity constraints. Includes priority-based construction heuristics, seed-based methods, savings-based approaches (Clarke & Wright), and local search metaheuristics.

Routing — Determines picker traversal paths. Includes layout-based heuristics (S-Shape, Return, Midpoint, Largest Gap), nearest neighbor, and exact methods (TSP, Ratliff-Rosenthal).

Scheduling — Assigns tours to pickers using list scheduling with priority dispatching rules (SPT, LPT, EDD, ERD).

Algorithm Cards¶

Each algorithm is annotated with requirements through YAML-based algorithm cards, enabling automated selection based on warehouse context:

model_name: RatliffRosenthal
problem_type: routing
description: >
  Implementation of DP for SPRP

requirements:
  layout:
    type:
      - conventional
    features:
      - start_node
      - end_node
      - closest_node_to_start
      - min_aisle_position
      - max_aisle_position
      - n_pick_locations
      - dist_pick_locations
      - dist_bottom_to_pick_location
      - n_blocks
    constraints:
      n_blocks:
        equals: 1
  resources:
    type:
      - human
    features:
  orders:
    type:
      - standard
    features:
  storage:
    type:
      - any
    features:
      - x
      - y

objective: Distance

implementation:
  class_name: RatliffRosenthal
  solver:
  type: heuristic

Quick Start¶

📘 Getting Started

Start here with an basic example to learn how to model a warehouse and use algorithms.

Understanding Domain Objects

🔬 Algorithm Reference

Complete catalog of implemented algorithms.

Algorithms

📚 API Documentation

Detailed API reference for all modules and classes.

API Reference

💡 Examples

Examples and benchmark evaluations.

Examples

Citation¶

If you use ware_ops_algos in your research, please cite:

@misc{bischoff2026ware_ops_algos,
 author = {Bischoff, Janik and Suba, Oezge Nur and Barlang, Maximilian and Kutabi, Hadi and Mohring, Uta and Dunke, Fabian and Meyer, Anne and Nickel, Stefan and Furmans, Kai},
 title = {ware_ops_algos},
 year = {2026},
 publisher = {GitHub},
 journal = {GitHub Repository},
 howpublished = {\url{https://github.com/kit-dsm/ware_ops_algos.git}},

}
